14  Rewinding work

14.1 Prep exercise.

Your task is to create a git repository that when you run our long viz command

git log --oneline --abbrev-commit --all --graph --decorate --color

Your screen shows this result (the commit hash abbreviations, like 1b2162e will vary on your repo)

test-rewind % git log --oneline --abbrev-commit --all --graph --decorate --color
* 50590c5 (HEAD -> main) made third edit
* 39f89db made second edit
* 1b2162e made first edit

Hint: You will need to start by making a directory called test-rewind then using cd test-rewind to change into it, and using git init to establish a git repo.

14.2 Why rewind?

When we are working we often want to try things out before we are 100% sure that they will work. We want to be able to experiment and find our way through a problem. If our experiment doesn’t work, we want to be able to step backwards in time, to find an earlier version that is a good new starting point.

In many ways this is identical to the idea of a “save point” in a game. We can step backwards in time and try again. We can reload that point at any time in the future. In our paper plane analogy, we can reach out and grab any tray in our repository.

Git enables us to save full copies of our working directory. We can then get back to the state of our work at any time we made a commit. When we check out a historical state, we get the files and the folders as as they were. So git actually swaps out the directory.

When I first started using git, I found this a bit confusing. usually when one restores from a backup, it is more like downloading a file. One gets to choose:

  • what to call the newly obtained older version
  • where to put it
  • what to do if there is a file that would be over-written.

What git does, though, is it swaps out all the files and folders with the previous version.

As we’ve seen, though, git is more fine-grained than a video game save-point. We often have files that have changed that we don’t want included in our save-point, this is why we have the git add stage before git commit.

Thus we can have untracked files or folders hanging around in our working folder. Git won’t change these when we do a checkout. So what happens is:

  1. git checks that all tracked files are in a “clean” state. This means that they are unchanged from the last commit. This is git checking that you have “saved your work” before it swaps out the files.
  2. git goes to its repository, locates the commit you ask for, and swaps all the tracked files and folders in the working directory.
  3. git remembers what commit you’ve moved to, so that if you make edits you can decide how they should be applied into the stream of commits in your repository.

Question for you to answer: What happens to untracked files when you run a git checkout

To move backwards in time we use the git checkout command. We have to let git know which commit we want to go back to. We can specify that using the name that git uses, which is the hash (e.g., 1b2162e) shown by git log.

Starting with our 3 commit test-rewind repo:

jlh5498@INFO-A64206 test-rewind % git log --oneline --abbrev-commit --all --graph --decorate --color
* 50590c5 (HEAD -> main) made third edit
* 39f89db made second edit
* 1b2162e made first edit

We can move to the first commit using

jlh5498@INFO-A64206 test-rewind % git checkout 1b2162e

which produces the output

Note: switching to '1b2162e'.

You are in 'detached HEAD' state. You can look around, make experimental
changes and commit them, and you can discard any commits you make in this
state without impacting any branches by switching back to a branch.

If you want to create a new branch to retain commits you create, you may
do so (now or later) by using -c with the switch command. Example:

  git switch -c <new-branch-name>

Or undo this operation with:

  git switch -

Turn off this advice by setting config variable advice.detachedHead to false

HEAD is now at 1b2162e made first edit

If we run our viz command we can see a little more:

jlh5498@INFO-A64206 test-rewind % git log --oneline --abbrev-commit --all --graph --decorate --color
* 50590c5 (main) made third edit
* 39f89db made second edit
* 1b2162e (HEAD) made first edit

See how the word HEAD now appears on the bottom line and not the top line? This is git’s way of telling us what is checked out.

When git says detached HEAD (a little intense sounding) git is highlight for us that our current working directory is not at the last commit. This means that if we try to make a new commit git wants us to know that it won’t just pop onto the top of the repo like usual.

For now, though, we can inspect files back at this version, and we can shift to another version (using checkout). For example we can move back to our top commit, using git checkout main.

If you see a error: pathspec 'main' did not match any file(s) known to git use git checkout master (newer git installs use main and older installs use master).

jlh5498@INFO-A64206 test-rewind % git checkout main
jlh5498@INFO-A64206 test-rewind % git log --oneline --abbrev-commit --all --graph --decorate --color
* 50590c5 (HEAD -> main) made third edit
* 39f89db made second edit
* 1b2162e made first edit

Notice how HEAD now points to the top commit? If we edit/add/commit our commits will drop back on top.

jlh5498@INFO-A64206 test-rewind % git add README
jlh5498@INFO-A64206 test-rewind % git commit -m "Made fourth edit"
[main ff7997b] Made fourth edit
 1 file changed, 1 insertion(+)
jlh5498@INFO-A64206 test-rewind % git log --oneline --abbrev-commit --all --graph --decorate --color
* ff7997b (HEAD -> main) Made fourth edit
* 50590c5 made third edit
* 39f89db made second edit
* 1b2162e made first edit

While we can always use the hash abbreviations like 50590c5 as names for commits, there is also a relative syntax.

git checkout HEAD~1

will get the commit one back from where HEAD is currently pointing. HEAD~2 will be 2 back, and so on. HEAD~ (without any number after the tilde) is a shortcut for HEAD~1

Remember, git swaps out all the tracked files when you do a checkout. If you have untracked files you will find they are unaffected by a git checkout. Create a file called my-untracked-file run git status then run git checkout <earlier-commit> (where <earlier-commit> is a hash for your first commit), then run git status again.

14.3 Undo

Sometimes (well often, really) we need to undo things we’ve done in git. Unfortunately there isn’t one Ctrl-Z type undo process in git. Here are three common scenarios with our edit, save, add, commit cycle.

14.3.1 git restore –staged Undo adding files (before commit)

When we add a file, we are placing the file onto the tray, ready to copy into the repository. In git language we use git add we are “staging” a set of changes ready to commit. If we run git status we will see the files added under Changes to be committeed (usually shown in green).

Sometimes we accidentally add files with changes that we don’t want to include in the commit (e.g., because they are unrelated to the current set of changes and would just clutter the commit up for people trying to understand it)

Helpful, the output of git status helps coach us how to fix this. We can use git restore --staged <file> This works with individual files, but <file> can also refer to a folder, in which case all the files inside that folder will be unstaged.

14.4 Revert - commits to undo commits

Once we have made a commit we face a different problem. Git is like a “ledger” in accounting that provides an “audit trail”: we can’t just easily delete something from history. Instead we can make a commit that reverses the mistake. One analogy that I like is that if the mistaken commit is “matter” then the revert commit is “anti-matter”, it exactly reverses all the changes of the mistaken commit. See https://github.blog/2015-06-08-how-to-undo-almost-anything-with-git/

This does leave the history looking a bit messy. We will explore other opportunities to tidy things up later in the course. One note at this point: if things like passwords get into the git history, it can be very difficult to entirely eliminate them from the history (and one never knows if others have unchanged copies) so generally if passwords or other secrets (like API keys) get into a git repository then it’s time to change the password or secret!
